Electrical Rough-In Planning Spreadsheet
- Regular price
-
$14.00 - Regular price
-
- Sale price
-
$14.00
This resource was incredibly helpful during our electrical rough-in process, and hopefully it will help you too! We have never taken on a job like this before, so the extra organization provided by the spreadsheet allowed us to:
- Plan space allocation for breakers in the main panel
- Locate breakers in the panel to minimize wire crossover, keeping wiring neat and professional
- Track progress as we finished each circuit, ensuring nothing was overlooked
- Generate an accurate materials list for the project, saving on procurement time & effort
What's Inside?
Circuit Breaker Layout: A representation of our panel layout with descriptions for each breaker. Easily changed or rearranged for your situation!
Individual Circuit Details: A table listing every circuit in our project, detailing the breaker amperage, number of poles, breaker type & part number (specific to a Square D Homeline panel), wire type & approximate length, and usage notes. Modify it to suit your needs.
Materials List: A listing of the breakers, boxes, wire, tools, and miscellaneous items we needed to purchase. This will vary for every project, but will give you a solid starting point for what you may need.
